CONTROLLER FEATURESSECTION 25
25.8. Menu 9 - Courtesy/Pillar Light
This feature is associated with the LightconnectionsontheController.Referto
page 33 of the manual for details on how to connect a Pillar or security light to the
Controller.
The Pillar Light circuit has multiple functions:
• It operates as a Courtesy Light andswitchesonforaselectabletime-period
every time the gate is activated
• The Courtesy Lightcanalsobeturnedonforthesametime-periodby
momentarily connecting the LIT terminal to the Com terminal via a pushbutton
• The Courtesy Light can also be turned on permanently by connecting the LIT
terminal to the Com terminal via a pushbutton, for three seconds.
Ashortpulsethereafterwillswitchthelightso.ThestatusLEDwillashonce
every two seconds to indicate that the Courtesy Light is on permanently. The
abovementioned facility can also be achieved via a remote learned to the system
and mapped to the Courtesy Light function from within the remotes menu
The gate will not open when using the LIT input.
• When the PED input is triggered, the Courtesy Lightashesforanadjustable
pre-ashtime(0to255seconds),beforethepedestriangateopens.
25.8.1. Courtesy Light Time
The time for which the Courtesy Light will remain activated can be set from four
seconds to ten hours in one second increments.
25.8.2. Light Prole
The Courtesy Light can be selected to operate according to one of the following:
• Courtesy Light as explained earlier
• Pre-ashingMode
• IfPre-ashingModeA,BorCisselected,thebehaviouroftheCourtesyLightwill
be as follows:
• Mode A will turn on the Courtesy Light only while the gate is moving
• Mode B will ashtheCourtesyLightduringthePre-openingand
Pre-closingDelays,aswellaswhilethegateismoving
• Mode C will turn ontheCourtesyLightduringthePre-openingandPre-closing
Delays, as well as while the gate is moving
• InthesePre-ashingModes,thetimedCourtesyLightfunctionalityisnot
available
