4. Specifications
FIGURE 2. V500 OVERALL DIMENSIONS
All dimensions shown in millimeters
FIGURE 1. V400 OVERALL DIMENSIONS
Page 8
All dimensions shown in millimeters
Physical Dimensions
1400mm extended
1000mm retracted
400mm stroke400mm stroke400mm stroke
Model V400
100mm
95mm
Model V500
1600mm extended
1100mm retracted
500mm stroke
95mm
100mm
