Centurion VECTOR2 - 3.1.6. PIRAC Mode (Beam Autoclose Mode)

1
5
Keys are specific to each operator - key number must be recorded
1. Wall bracket (standard)
2. Wall bracket pin
3. VECTOR2 gate operator (complete
assembly)
4. 12mm snap ring
5. Gate warning decal
6. Gate operator keys
7. Gate bracket pin
8. Gate bracket
9. Stainless steel cap screw M6 x 25
10. Origin body
11. Stainless steel M6 nut
12. 14mm snap ring
5. Product Identification
1. 12V 7.2Ah Battery (user supplied -
not part of kit)
2. VECTOR2 controller with built-in
receiver
3. Charger
3
4
2
9
12
7
6
8
10
11
2
3
6
1
5
7
Page 12
FIGURE 3A. PRODUCT IDENTIFICATION
FIGURE 3B. CONTROL BOX INCLUDING CHARGER AND CONTROLLER
4
4. CENTURION remote controls
5. User Guide
6. Installation Manual
7. Control Box
