17. Wiring Diagram for Other Inputs
Holiday Lockout
keyswitch/keypad
(normally-closed)
Pedestrian
keyswitch/keypad
(normally-open)
Pillar Light
pushbutton
(normally-open)
Status
LED
A
U
X
Solenoid
or strike lock
FIGURE 69. WIRING OF OTHER INPUTS
Page 43
