Mechano Kit Installation Options
This kit is useful when fitting VECTOR2 to existing installations, and also makes adjustments
easier when doing new installations.
FIGURE 19. INSTALLATION WHEN THE PILLAR IS WIDE
FIGURE 20. INSTALLATION WHEN THE PILLAR IS ON AN IRREGULAR SURFACE
FIGURE 21. INSTALLATION ON A PALISADE FENCE
FIGURE 22. INSTALLATION ON AN ANGLED WALL
