FIGURE 67. WIRING OF SAFETY DEVICE
Page 41
Opening Safety Beams
15. Wiring Diagram for Opening Safety Beams
IRB Tx
IRB Receiver
12V/24V +
12V/24V -
12V/24V -
COM
12V/24V +
NC
NO
