1. VECTOR2 Wall Adaptor Kit packing leaflet
2. M10 hexagon nuts
3. Wall adaptor plate
4. M10 x 20 countersunk screw
FIGURE 3C. WALL ADAPTOR KIT
3
4
2
1
1. VECTOR2 High-security Kit packing leaflet
2. Padlocks
3. Wall bracket (high-security)
1. VECTOR2 securing plate (short)
2. VECTOR2 Mechano Kit packing leaflet
3. M10 x 35 bolt
4. M10 x 35 bolt
5. VECTOR2 securing plate (long)
1. VECTOR2 Gate Adaptor Kit packing leaflet
2. M6 x 16 countersunk cap screw
3. Gate bracket spreader plate
4. M6 hexagon nuts
FIGURE 3D. HIGH-SECURITY KIT
FIGURE 3E. MECHANO KIT
FIGURE 3F. GATE ADAPTOR KIT
