SECTION 6 CESSNA
WEIGHT AND BALANCE/ MODEL T182T NAV III
EQUIPMENT LIST GFC 700 AFCS
U.S.
Figure 6-9 (Sheet 3)
ITEM NO EQUIPMENT LIST DESCRIPTION
REF
DRAWING
WT
LBS
ARM
INS.
26 - FIRE PROTECTION
26-01-S FIRE EXTINGUISHER 0501011-3 5.3* 29.0*
- FIRE EXTINGUISHER, HAND TYPE A352GS 4.8 29.0
- MOUNTING CLAMP AND HARDWARE 1290010-1 0.5 29.0
27 - FLIGHT CONTROLS
27-01-S DUAL CONTROLS, RIGHT SEAT 0706015-4 5.9* 12.9*
- CONTROL WHEEL, COPILOT 0713377-6 2.3 26.0
- RUDDER AND BRAKE PEDAL, COPILOT 0760650-4 3.6 6.8
27-02-O RUDDER PEDAL EXTENSION (SET OF 2)
(INSTALLED ARM SHOWN)
0501082-2 2.9 8.0
28 - FUEL
28-01-R AUXILIARY FUEL PUMP - S100-00-4 0716158 1.9 -12.0
28-02-R FUEL SENDER, FLOAT TYPE - S3852-3, -4 0720701 0.1 56.3
or
FUEL SENDER, VIBROMETER - 76-207-4, -5 0720701 0.9 56.3
30 - ICE AND RAIN PROTECTION
30-01-S ELECTRIC HEATED BOOTS, PROPELLER 0750645 5.1 -22.0
30-02-S STALL SENSOR HEAT AND PITOT HEAT 0720701 0.7 28.0
31 - INDICATING/RECORDING SYSTEM
31-01-S RECORDING HOURMETER - C664503-0103 0706015 0.5 16.7
31-02-R STALL WARNING SYSTEM
- STALL WARNING HORN - 0718007-1 0718009 0.5 40.0
- WING UNIT, STALL WARNING - S1672-9 0720701 0.3 25.6
31-03-R GEA 71 ENGINE/AIRFRAME UNIT 3930368 2.2 11.4
31-04-R GTP 59 OUTSIDE AIR TEMPERATURE (OAT)
PROBE
0706015 0.1 41.5
32 - LANDING GEAR
32-01-R WHEEL BRAKE AND TIRE, 6.00 X 6 MAIN (2) 0741625-19 37.1* 58.6*
- WHEEL ASSY CLEVELAND 40-75B (EACH) C163001-0301 7.8 58.9
- BRAKE ASSY CLEVELAND 30-52 (EACH) 030-05219-1 1.8 55.5
- TIRE, 6-PLY (EACH) C262003-0204 7.9 58.9
- TUBE (EACH) C262023-0102 1.3 58.9
32-02-R WHEEL AND TIRE ASSY, 5.00 X 5 NOSE 0540000-2 8.8* -7.1*
- WHEEL ASSY CLEVELAND 40-77 1241156-12 2.8 -7.1
- TIRE, 6-PLY C262003-0202 4.6 -7.1
- TUBE C262023-0101 1.4 -7.1
32-03-A WHEEL FAIRING AND INSTALLATION 0741650-1 16.4* 44.5*
- WHEEL FAIRING, NOSE 0742411-1 3.1 -6.0
- WHEEL FAIRINGS, MAIN (SET OF 2) 0741648-1, -2 9.5 60.6
32-04-A HUB CAPS, WHEELS 0741048-8 0.1 62.1
T182TPHBUS-01
6-22
