CESSNA SECTION 6
MODEL T182T NAV III WEIGHT AND BALANCE/
GFC 700 AFCS EQUIPMENT LIST
U.S.
Figure 6-9 (Sheet 4)
ITEM NO EQUIPMENT LIST DESCRIPTION
REF
DRAWING
WT
LBS
ARM
INS.
33 - LIGHTS
33-01-S MAP LIGHT IN CONTROL WHEEL 0760149-5 0.2 21.5
33-02-S COURTESY LIGHTS UNDER WING 0700615-18 0.7 61.7
33-03-S FLASHING BEACON, GROUND RECOGNITION 0701042-6, -7 0.8 253.1
33-04-R STROBE LIGHT 0723207 3.2 40.4
33-05-S LANDING AND TAXI LIGHT, HID 1221059-14, -15 2.2 26.8
34 - NAVIGATION
34-01-R STANDBY AIRSPEED INDICATOR - S3325-9 0706015 0.7 16.2
34-02-R STANDBY ATTITUDE INDICATOR - S3326-8 0706015 2.2 14.0
34-03-R STANDBY ALTIMETER, SENSITIVE WITH 20
FOOT MARKINGS, INCHES OF MERCURY AND
MILLBARS - S3828-1
0706015 0.9 15.3
34-04-S ALTERNATE STATIC AIR SOURCE 0701028-4 0.2 15.5
34-05-R COMPASS, MAGNETIC 1213679-5 0.5 18.0
34-06-R TRANSPONDER 3940389
- GTX-33 TRANSPONDER 3910317-5 3.6 134.0
- CI 105-16 TRANSPONDER ANTENNA 3960195 0.4 86.5
34-07-R PFD DISPLAY 3930374
- GDU-1044B DISPLAY 3910317-1 6.5 15.0
34-08-R MFD DISPLAY 3930374
- GDU-1044B DISPLAY 3910317-1 6.5 15.0
34-09-R ATTITUDE HEADING REFERENCE SENSOR
(AHRS)
3940389
- GRS 77 AHRS 3910317-3 2.6 134.0
- GMU 44 MAGNETOMETER 3940394 0.3 44.0
34-10-R AIR DATA COMPUTER 3930368
- GDC 74A AIR DATA COMPUTER 3910317-6 3.6 11.4
34-11-O WX 500 STORMSCOPE
- PROCESSOR - S3100-276 3940403 2.5 162.0
- ANTENNA - 805-10930-001 3960206 1.0 175.4
34-12-S GDL-69A DATALINK 3930368 2.8 11.4
34-13-O AUTOMATIC DIRECTION FINDER (ADF)
- KR 87 ADF RECEIVER 3930495 3.2 12.2
- ADF ANTENNA 3960192 4.2 39.3
34-14-O DISTANCE MEASURING EQUIPMENT (DME)
- KN 63 REMOTE DME 3940449 2.8 177.2
- CI 105-16 DME ANTENNA 3960232 0.4 114.5
34-15-O KTA 810 TRAFFIC ADVISORY SYSTEM 3940441 8.8 165.0
T182TPHBUS-01
6-23
