Chattanooga 2761 - Ultrasound Specifications; Ultrasound; Ouput Power; Head Warming Feature

Vectra Genisys® Therapy System
SPECIFICATIONS
24
Frequency .............................1 MHz, ± 5%; 3.3 Mhz, ±5%
Duty Cycles ...........................10%, 20%, 50%, Continuous
Pulse Frequency ...........................................100 Hz
Pulse Duration .......1 mSec, ±20%; 2 mSec, ±20%; 5 mSec, ±20%
Output Power
10 cm
2
Crystal .................0-20 W at 1MHz, 0-10 W at 3.3 MHz
5 cm
2
Crystal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0-10 W, 1 and 3.3 MHz
2 cm
2
Crystal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0-4 W, 1 and 3.3 MHz
1 cm
2
Crystal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0-2 W 3.3 MHz Only
Amplitude ....................0 to 2.5 w/cm
2
in continuous mode,
0-3 w/cm
2
in pulsed modes
Output accuracy ...................±20% above 10% of maximum
Temporal Peak to Average Ratio: ....2:1, ± 20%, at 50% Duty Cycle
5:1, ± 20%, at 20% Duty Cycle
9:1, ± 20%, at 10% Duty Cycle
Beam Nonuniformity Ratio . . . . . . . . . . . . . . . . . . . . . . 5.0 : 1 maximum
Beam Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Collimating
IPXX Rating for Unit ...........................................IPX0
IPXX Rating for Applicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IPX7
ULTRASOUND SPECIFICATIONS
Ultrasound
Effective Radiating Areas. . . . . . . . . . . . 10 cm
2
Crystal: 6.8 cm
2
– 10 cm
2
5 cm
2
Crystal: 3.5 cm
2
– 5 cm
2
2 cm
2
Crystal: 1.4 cm
2
– 2 cm
2
1 cm
2
Crystal: 0.7 cm
2
– 1 cm
2
Treatment Time ..........................................1-30 min
Head Warming Feature
The Head Warming feature of an Vectra Genisys Combination
Therapy System utilizes Ultrasound output resulting in warming
of the Sound Head to increase patient comfort.
With Head Warming enabled, ultrasound is emitted without
pressing the Start button. The Applicator LED will not illuminate
during the Head Warming period. US Channel will indicate "Head
Warming".
Output . . . . . . . . . . . . . . . . . . . . . . . 0 - 50% Cycling of maximum power
Frequency ................................................ 3.3 Mhz
Sound Head Temperature . . . . . . . . . 29.4 °C - 43.3 °C (85 °F - 110 °F)
Do not apply the Ultrasound Applicator to the patient
during the Head Warming period. Applicator must remain in
Applicator Hook during the Head Warming period.
