Chino KP3000 User Manual

- 56 -
Analog setting value (40001 to 49999)
System setting Program pattern information
No. Contents No. Contents No. Contents No. Contents
40601 40701 48001 Display back light 49001
40602 40702 48002 Display contrast 49002
40603 40703 48003 Key backlight 49003
Pattern No. [for pattern
R/W]
40604 40704 48004 49004 Step No. [for pattern R/W]
40605 40705 48005 49005 Step repeat
40606 40706 48006 49006 SV
40607 40707 48007 49007 Time, hours or minutes
40608 40708 48008 49008
Time, minutes or
seconds
40609 40709 48009 49009
40610 40710 48010 49010 SV No.
40611 40711 48011 49011
40612 40712 48012
External signal allocation,
Terminal No.12
49012
40613 40713 48013
External signal allocation,
Terminal No.13
49013
40614 40714 48014
External signal allocation,
Terminal No.14
49014
40615 40715 48015
External signal allocation,
Terminal No.15
49015
40616 40716 48016
External signal allocation,
Terminal No.16
49016
40617 40717 48017
External signal allocation,
Terminal No.17
49017
40618 40718 48018 49018
40619 40719 48019
External signal allocation,
Terminal No.19
49019
40620 40720 48020
External signal allocation,
Terminal No.20
49020 Time signal 1 No.
40621 40721 48021
External signal allocation,
Terminal No.21
49021 Time signal 2 No.
40622 40722 48022
External signal allocation,
Terminal No.22
49022 Time signal 3 No.
40623 40723 48023
External signal allocation,
Terminal No.23
49023 Time signal 4 No.
40624 40724 48024
External signal allocation,
Terminal No.24
49024 Time signal 5 No.
40625 40725 48025 49025 Time signal 6 No.
40626 40726 48026
External signal allocation,
Terminal No.26
49026 Time signal 7 No.
40627 40727 48027
External signal allocation,
Terminal No.27
49027 Time signal 8 No.
40628 40728 48028
External signal allocation,
Terminal No.28
49028
40629 40729 48029
External signal allocation,
Terminal No.29
49029
40630 40730 48030
External signal allocation,
Terminal No.30
49030
40631 40731 48031
External signal allocation,
Terminal No.31
49031
40632 40732 48032
External signal allocation,
Terminal No.32
49032
40633 40733 48033
External signal allocation,
Terminal No.33
49033
40634 40734 48034 49034
40635 40735 48035 49035
40636 40736 48036 49036
40637 40737 48037 49037
40638 40738 48038 49038
40639 40739 48039 49039
40640 40740 48040 49040
Existing set step count
(R)
40641 40741 48041 49041 Start SV
40642 40742 48042 49042
40643 40743 48043 49043 Link destination pattern No.
40644 40744 48044 49044
40645 40745 48045 49045
40646 40746 48046 49046
40647 40747 48047 49047
40648 40748 48048 49048 Time unit
40649 40749 48049 49049 SV during reset
40650 40750 48050 49050
