CHINT NVF2G-S Series User Manual

product specification
W
H
D
W1 H1 D1
weight (Kg)
Remark
118 187
173 107
175
110
2.4
see picture 5.1
155
247
189 140
232
125
3.6
see picture 5.1
191
378
193
90 362
129
10.5
see picture 5.2
215
426
213 120
407
164
15
see picture 5.2
259
433
240
140
408
179
26
see picture 5.3
NVF2G-S-1.5/PS4
NVF2G-S-1.5/TS4 (2.2/PS4)
NVF2G-S-2.2/TS4 (3.7/PS4)
NVF2G-S-3.7 TS4 (5.5/PS4)/
NVF2G-S-5.5/TS4 (7.5/PS4)
NVF2G-S-7.5/TS4 (11/PS4)
NVF2G-S-11/ S4 (15/PS4)T
NVF2G-S-15/TS4 (18.5/PS4)
NVF2G-S-18.5/TS4 (22/PS4)
NVF2G-S-22/TS4 (30/PS4)
NVF2G-S-30/TS4 (37/PS4)
NVF2G-S-37/TS4 (45/PS4)
Figure 5.4 NVF2G-S-75/TS4~NVF2G-S-315/PS4 outline and installation dimensions
Figure 5.5 NVF2G-S~315/TS4 ~-NVF2G-S-400/TS4 outline and installation dimensions
Table 5.1 Product appearance and installation dimensions and weight
