4
Structural features and working principle
4.1 Product structure feature map
Figure 4.1 NVF2G-S-1.5/PS~NVF2G-S - 11/PS4 Outline Components
Figure 4.2 NVF2G-S- 11/TS4 ~ NVF2G-S - 30/PS4 Outline Components
FAN
Panel (Top)
Keyboard
Panel(Bottom)
INSTALL HOLE
SHELL
NAMEPLATE
BASEPLATE
FAN
Panel
Panel base
Keyboard
INSTALL HOLE
SHELL
NAMEPLATE
007
