CHINT NVF2G-S Series - Dimensions of Display Box and Pallet

product specification
W
H
D
W1 H1 D1
weight (Kg)
Remark
352
603
257
240
577
197.5
34
see picture 5.3
406
631
272
126
600
224
58
see picture 5.4
470 807
352
150
769
226.5
108
see picture 5.4
540
892 390
180
848
256
121
see picture 5.4
710 1020
3 86
250
978
284
171.5
see picture 5.4
734
1200
426
250
1152
3 13
280
see picture 5.5
NVF2G-S-45/TS4 (55/PS4)
NVF2G-S-55/TS4 (75/PS4)
NVF2G-S-75/TS4 (90/PS4)
NVF2G-S-90/TS4 (110/PS4)
NVF2G-S-110/TS4 (132/PS4)
NVF2G-S-132/TS4 (160/PS4)
NVF2G-S-160/TS4 (185/PS4)
NVF2G-S-185/TS4 (200/PS4)
NVF2G-S-200/TS4 (220/PS4)
NVF2G-S-220/TS4 (245/PS4)
NVF2G-S-245/TS4 (280/PS4)
NVF2G-S-280/TS4 (315/PS4)
NVF2G-S-315/TS4(355/PS4)
NVF2G-S-355/TS4 (400/PS4)
NVF2G-S-400/TS4
5.2 Dimensions of display box and pallet
Figure 5.6 shows the size of the box
Figure 5.7 Outline Dimensions of the Pallet
Note: 73.5*111.5 is the size of the metal opening recommended for installing the pallet , and the thickness of the sheet
metal is recommended not to be greater than 1.5mm;
