CHINT NVF2G-S Series - Advanced Parameters: V;F, Vector, Protection, Monitoring, Terminals

function
code
name
default
value
Predetermined area
Parameter Description
F2.05
Number of motor poles
Model
confirmed
2 ~24
F2.06
Motor rated speed
1 430 rpm
(0~ 65535)rpm
F2.07
Asynchronous motor
stator resistance
Tuning
parameters
(0.001~63.535) Ω(inverter power≤
55kW)
(0.0001~6.5535) Ω(inverter power>
55k W)
F2.08
Asynchronous motor
rotor resistance
Tuning
parameters
(0.001~63.535) Ω (inverter power ≤
55kW)
(0.0001~6.5535) Ω (inverter power >
55k W)
F2.09
Asynchronous motor
leakage inductance
Tuning
parameters
(0.001~63.535) Ω (inverter power ≤
55kW)
(0.0001~6.5535) Ω (inverter power >
55k W)
F2.10
Mutual inductance
reactance of
asynchronous motor
Tuning
parameters
(0.1~6553.5) mH (inverter power <=
55kW)
(0.01~655.35) m H (inverter power >
55k W)
F2.11
Asynchronous motor
no-load current
Tuning
parameters
0.01A~F2.03 (inverter power<=55kW)
0.1A~F2.03 (inverter power>55 kW)
● Motor static self-learning: suitable for occasions where it is difficult to separate the motor from the load
and dynamic tuning operation is not allowed
1. Accurately input the motor nameplate parameters: F2.00～F2.06;
2. Write parameter F2.22 as 1 , then press Run to run the inverter;
3. The words " -TUN-" appear on the panel, and the learning is completed;
● Motor dynamic self-learning: suitable for occasions where the motor is easily separated from the
application system :
1. Accurately input the motor nameplate parameters: F2.00～F2.06;
2. Write parameter F2.22 as 2, then press Run to run the inverter ;
3. The words " -TUN-" appear on the panel, and the learning is completed;
Notice
1. When performing parameter self-learning, the motor parameters must be entered correctly
according to the motor nameplate, otherwise the motor parameter self-learning may be
inaccurate.
2. During the motor parameter self-learning process, the learning process can be terminated by
pressing the STOP button , but it may cause incomplete motor parameter self-learning results.
3. During the self-learning process of the motor parameters, if there is an abnormality, it will report
a poor self - tuning fault ( E.tE ).
8.5 V/F control parameters
8.5.1 Linear V /F , multi-point V /F , and torque -reducing V /F curves
function
code
name
default
value
Predetermined area
Parameter Description
0: Straight line V /F curve
1: 2 power drop torque V /F curve
2 : 1.7 power drop torque V /F curve
3 : 1.2 power drop torque V /F curve
4: Multi-point V /F curve
F4.00
V /F curve setting
0 0~4
0.0% (automatic torque boost)
(0.1 ~ 30.0) % (relative to the rated
voltage of the motor)
F4.01
torque boost
Model
confirmed
(0.0 ~ 30.0) %
050
