CHINT NVF2G-S Series User Manual

1.5 kW
ACL-0005-EISC-2
Does not support installation
OCL-0005-EISC-1
2.2 kW
ACL-0007-EISC-2
Does not support installation
OCL-0005-EISC-1
3.7 kW
ACL-0010-EISC-2
Does not support installation
OCL-0010-EISC-1
5.5 kW
ACL-0015-EISC-2
Does not support installation
OCL-0015-EISC-1
7.5 kW
ACL-0020-EISC-2
Does not support installation
OCL-0015-EISC-1
11 kW
ACL-0030-EISCL-2
Does not support installation
OCL-0030-EISCL-1
15 kW
ACL-0040-EISCL-2
Does not support installation
OCL-0030-EISCL-1
18.5 kW
ACL-0040-EISCL-2
Does not support installation
OCL-0040-EISCL-1
22 kW
ACL-0050-EISCL-2
Does not support installation
OCL-0050-EISCL-1
30 kW
ACL-0060-EISCL-2
Does not support installation
OCL-0060-EISCL-1
37 kW
ACL-0090-EISCL-2
Does not support installation
OCL-0080-EISC-1
45 kW
ACL-0090-EISCL-2
DCL-0115-EIDH-4
OCL-0090-EISC-1
55 kW
ACL-0120-EISCL-2 DCL-0160-UIDH-4 OCL-0120-EISC-1
75 kW
ACL-0150-EISH-2
DCL-0180-UIDH-4
OCL-0150-EISH-1
90 kW
ACL-0200-EISH-2
DCL-0250-UIDH-4
OCL-0200-EISH-1
110 kW
ACL-0250-EISH-2 DCL-0250-UIDH-4
OCL-0200-EISH-1
132 kW
ACL-0250-EISH-2
DCL-0340-UIDH-4
OCL-0250-EISH-1
160 kW
ACL-0330-EISH-2 DCL-0460-UIDH-4
OCL-0330-EISH-1
185 kW
ACL-0390-EISH-2 DCL-0460-UIDH-4
OCL-0330-EISH-1
200 kW
ACL-0390-EISH-2 DCL-0460-UIDH-4
OCL-0390-EISH-1
220 kW
ACL-0490-EISH-2
DCL-0650-UIDH-4
OCL-0490-EISH-1
245 kW
ACL-0490-EISH-2
DCL-0650-UIDH-4
OCL-0490-EISH-1
280 kW
ACL-0600-EISH-2
DCL-0650-UIDH-4
OCL-0530-EISH-1
315 kW
ACL-0600-EISH-2
DCL-1000-UIDH-4 OCL-0600-EISH-1
355 kW
ACL-0800-EISH-2
DCL-1000-UIDH-4 OCL-0660-EISH-1
400 kW
ACL-0800-EISH-2
DCL-1000-UIDH-4 OCL-1000-EISH-1
450 kW
ACL-1000-EISH-2 DCL-1000-UIDH-4 OCL-1000-EISH-1
Inverter model
Input reactor
DC reactor
Output reactor
A.2 Reactor selection
Table A. 2 Reactor selection
Notice
1. Optional built-in braking unit needs to be customized.
2. When the brake assembly is connected externally:
1) The polarities of , (or , or , ) cannot be reversed, otherwise there is a risk of damaging
the frequency converter, or even causing a fire;
2) The wiring length of the brake unit should not exceed 10 m , and twisted-pair or tight double-wire parallel
wiring should be used.
3. When connecting external braking components or external braking resistors, please change the "overvoltage
stall selection" to "prohibited" (the parameter number of FE.07 is " 0"), otherwise, within the set deceleration
time will not stop.
+1 +2
Both the input reactor and the output reactor are external options , and the recommended models
are shown in the table;
Notice
A.3 Classification table of braking unit and DC reactor
Table A.3 Classification table of braking unit and DC reactor
1
Standard built-in brake unit
NVF2G-S-1.5/PS4～NVF2G-S-30/PS4
2
Optional built-in brake unit
NVF2G-S-30/TS4～NVF2G-S-110/PS4
3
Optional external braking unit
NVF2G-S-110/TS4～NVF2G-S-400/TS
4
Does not support the installation of DC reactors
NVF2G-S-1.5/PS4～NVF2G-S-45/PS4
5
Optional external DC reactor
NVF2G-S -45/TS4～NVF2G-S-110/PS4
6
Standard external DC reactor
NVF2G-S-110/TS4～NVF2G-S-315/PS4
7
Standard built-in DC reactor
NVF2G-S-315/TS4～NVF2G-S-400/TS4
serial number
Functional Classification
power section
086
NVF2G-S Series Inverter User's Guide
