Function
Description
address
definition
Data Meaning Description
Power-down
save
Read and
write
properties
0x340A
Input terminal state
0x340B
Output terminal state
0x340C
Torque setpoint
0x340D
Analog AI1 value
0x340E
Analog AI2 value
0x340F
reserve
0x3410
reserve
0x3411
PLC current segment speed
0x3412
set speed
Inverter stop state
display parameter
address
0x3500
set frequency
/
R
0x3501
bus voltage
0x3502
Input terminal state
0x3503
Output terminal state
0x3504
PID given value
0x3505
PID feedback value
0x3506
Torque setpoint
0x3507
Analog AI1 value
0x3508
Analog AI2 value
0x3509
reserve
0x350A
reserve
0x350 B
set speed
Inverter fault
0x3600
The fault information is consistent with the fault
type serial number in the function code, and what
is fed back to the host computer is the hexadecimal
data value instead of the fault symbol.
/
R
Inverter running
state display
parameter address
/
R
9.7 Parameter management
ćć The Modbus master station can obtain the group number and group number value of the system parameter
from the CPU board through the corresponding command, and obtain the group number of the corresponding
group. It is stipulated that the communication function code is "0x03", and the communication address is
defined as in Table 9.5 .
Table 9.5 Parameter management function description
Function Description
Mailing address
description
data meaning
Remark
Get the number of groups
0x4200
The group value of the parameter
contained in the system
Parameter group values
contained in the drive
Get the value of the first
group number
0x4201
Group number 1 value
The value of the group number
is consistent with the value
obtained by 0x4200 .
Get the value of the second
group number
0x4202
The second group number value
Get the value of the third
group number
0x4203
The third group number value
... ... ...
Get the value of the Max
group number
0x42xx
( xx=Max )
The Max group number value
071
NVF2G-S Series Inverter User's Guide
