FAN
Panel
Panel base
Keyboard
INSTALL HOLE
SHELL
NAMEPLATE
Figure 4.3 NVF2G-S-30/TS4 ~ NVF2G-S-75/TS4 external parts diagram
Figure 4.4 NVF2G-S -75/TS4 ~ NVF2G-S-315/PS4 Outline Components
008
NVF2G-S Series Inverter User's Guide
RINGS
FAN
Panel
Panel base
Keyboard
INSTALL HOLE
SHELL
NAMEPLATE
