Description of Panel
4-9
short zeroing test error, the display will show [FAIL] to indicate the test has encountered a
problem. Please check the test cable to see if it is disconnected or there is any bad
connection of the clip. Do the short zeroing test again after the examination.
[PASS] will appear on the display to indicate the open zeroing test is done when the test is
correct. Press [EXIT] in the following screen to quit.
4.4.3 Setting LCRZ Components Parameters
1. When the meter is powered on normally, press [Measure Display] to enter the LCRZ
components parameters analysis test screen as shown below:
2. Below explains the setting of each parameter:
FREQ.: It sets the frequency for test. The 11021 has 100Hz, 120Hz, 1KHz, and 10KHz
four frequencies, while 11021-L has 1KHz, 10KHz, 40kHz and 50kHz. The
default setting is 1KHz. Press [F1] can switch the frequency sequentially or
press [], [] to select a frequency.
LEVEL: It sets the voltage for setting. There are constant voltages 0.25Vrms and
1.0Vrms for 11021 and 50mVrms and 1.0Vrms for 11021-L. The default setting
is 1.0V. Press [F2] directly or [], [] for switch.
PARA.: It sets the parameter for test. The parameters are divided into three groups.
The primary parameters of L, C, R, and Z are the first group; Series and
Parallel modes are the second group; while Q, D, ESR, , and Xs parameters
< CORRECTION SHORT >
F: 10KHz Rs: 0.001 -
PASS
Press ‘EXIT’ to exit. EXIT
F1
F2
F3
F4
Å Quit the screen
< MEAS. DISPLAY > FREQ.: 1KHz Å Set the frequency for test
Cp : 0.9999 nF LEVEL: 1.00 V Å Set the voltage for test
D : 0.0001 PARA.: Cp - D Å Set the parameter for test
NEXT PAGE 1/3
F1
F2
F3
F4
Å Switch to 2
nd
page
< MEAS. DISPLAY > RANGE:
H 100K Å Set the range
Cp : 0.9999 nF SPEED: FAST Å Set the measurement speed
D : 0.0001 TRIG.: INT. Å Set the trigger mode
NEXT PAGE 2/3
F1
F2
F3
F4
Å Switch to the 3
rd
page
< MEAS. DISPLAY > BIN : OFF ÅSet the sorting test
Cp : 0.9999 nF COMP.: OFF ÅSet HI/LO limit for comparison
D : 0.0001
NEXT PAGE 3/3
F1
F2
F3
F4
ÅSwitch to the 1
st
page
