Page #36 background image
LCR Meter 11021 / 11021-L User’s Manual
4-10
are the third group of secondary parameters. Press [F3] or [], [] to move
the cursor and then press [], [] to select the parameter to be set.
RANGE: It sets the range for test. A indicates Auto (auto ranging), H indicates Hold
(manually fixed range). Press [F1] or [], [] to move the cursor and press
[], [] to switch the range. There are 100K, 10K, 1K, 100, and 10
five ranges. When selecting 3 in 0.25V (for 11021) / 50mV (11021-L) Range
Mode, there are 100K, 1K and 10 available for selection.
SPEED: It sets the measurement speed for test. There are speeds of FAST, MEDIUM
and SLOW. The lower the speed the more stable it is. Press [F2] or [], []
to switch the measurement speed. The default setting is FAST.
TRIG.: It sets the trigger mode for test. There are Internal (continuous trigger),
External (trigger externally) and Manual (trigger manually) three modes. Press
[F3] directly or [], [] to switch the mode. The default setting is Internal.
BIN. It sets the binning function for test. Press [F1] to switch it to OFF or ON. When
it sets to ON, the BIN X will appear on the screen. The parameter setting is via
the BINNING in MAIN INDEX screen.
COMP. It sets the maximum/minimum limit for comparison test. There are OFF,
ON-VAL, ON-Δ, and ON-Δ% four types. Press [F2] or [], [] to switch it. The
parameter setting is via the COMPARE in MAIN INDEX.
When the parameter setting is done, press [SYSTEM SETUP] to save the changed
values.
4.4.4 Setting BINNING
1. When the meter is powered on normally, press [MAIN INDEX] to enter the main screen
as shown below:
Press [F1] to enter the binning test screen as shown below.
Press [F1] to enter the setting screen as shown below.
MAIN INDEX > INNING
Å
Set the sorting test
OMPARE
Å
Set HI/LO limit for comparison
ORRECTION
Å
Zeroing calibration
F1
F2
F3
F4
< BINNING > SETTING Å Set the condition
COUNT Å Set the counter
F1
F2
F3
F4
