LCR Meter 11021 / 11021-L User’s Manual

4-6

TRIGGER EDGE:

It sets the RISING and FALLING edge trigger. The default setting is FALLING edge

trigger.

LINE FREQUENCY:

It sets the line frequency to 50Hz or 60Hz for AC110V/220V power source. The default

setting is 60Hz. 11021 can be synchronized with 50Hz/60Hz line frequency; however,

the 11021-L can only be synchronized with 50Hz line frequency.

BAUD RATE:

There are 2400, 4800, 9600, 19200 and 38400 five rates available for setting. The

default setting is 19200.

0.25V Range Mode (for 11021) / 50mV Range Mode (for 11021-L):

The test range will be 3 or 5 ranges when in 0.25V (for 11021) / 50mV (11021-L). The

default setting is 5.

5: 10/100/1k/10k/100k ohm, 5 ranges in total, 3: 10/1k/100k ohm, 3 ranges in total.

4.3.2 Memory Manage

In SYSTEM SETUP, press [F2] (MEMORY MANAGE) it will show the following screen:

Enter the correct password to access the Memory Manage function.

4.4 Description of Operation

4.4.1 Open Correction

1. When the meter is powered on normally, press [MAIN INDEX] to enter the main screen

as shown below:

2. Press [F3] to show the following screen:

< SYSTEM SETUP > CALIBRATION ÅCalibrating the range

PASSWORD: ▋ MEMORY MANAGE ÅManaging the memory

SYSTEM CONFIG ÅSetting the system

< MAIN INDEX > BINNING ÅSet the sorting test

COMPARE ÅSet HI/LO limit for comparison

CORRECTION ÅZeroing calibration

< CORRECTION > OPEN Å Open zeroing

SHORT Å Short zeroing
