Description of Panel
4-13
3. Press [F1] to enter the setting screen as shown below:
PRI_NOMINAL: The nominal of DUT’s primary parameter, the setting range is
0000.0000p~9999.9999G.
PRI_HI_LIMIT: The high limit of primary parameter.
PRI_LO_LIMIT: The low limit of primary parameter.
SEC_HI_LIMITL: The high limit of secondary parameter.
SEC_LO_LIMIT: The low limit of secondary parameter.
Press [F4] can select the high/low limit VALUE or PERCENT for primary parameter. The
setting range for value is –999.9999G ~ +999.9999G and for PERCENT is –9999.99% ~
+9999.99%. The format of secondary parameter is fixed to VALUE and the setting range
is –999.9999G ~ +999.9999G.
When exiting the COMP SETTING screen, check if the HI and LO setting parameters are
reasonable. Once HI < LO, the HI and LO settings will be switched automatically.
4. Refer to section 4.4.4 Setting BINNING for det
ail setting operation. When the setting is
done, press [MAIN INDEX] to return to the previous screen (as shown above). Next, press
[F2] (COUNT) to begin the test. The test screen appears as below:
< COMPARE > SETTING Å Set the condition
COUNT Å Set the counter
F1
F2
F3
F4
< COMP. SETTING > Cs-D INCREASE Å Increase the digit number.
PRI_NOMINAL: +000.0000-F DECREASE Å Decrease the digit number.
PRI_HI_LIMIT: 0.0000 -F DIGIT Å Move the cursor right.
PRI_LO_LIMIT: 0.0000 -F VALUE
F1
F2
F3
F4
Å Hi/Low limit of primary.
PRIMARY SECONDARY RESET
GO: 44 GO: 0
HI: 64 HI: 131 TOTAL:
LO: 23 LO: 0 131
F1
F2
F3
F4
