Programmable AC Source 61601/61602/61603/61604 User’s Manual
1-4
3.8.1). If pressing the key on CHOICE PAGE, the user
can save system data (see 3.8.2).
5
/ -
----------or---------
RECALL
Backspace and Minus command key: Pressing this key
will erase the keyin number. Or it may show " - ", if no
number is in front of cursor. Under shift mode, pressing the
key on MAIN PAGE, the user can recall the output setting
(see
3.8.1). If pressing the key on CHOICE PAGE, the
user can recall system data (see 3.8.2).
6
OUT/QUIT command key: Pressing this key may enable
the ac source output voltage or quit the output voltage.
7
Shift mode selection key: Pressing this key will switch the
ac source from normal operational mode to the shift mode.
8
0 to 9 , and
------------or-----------
HELP
Numeric and decimal keys: The user can program
numeric data by pressing the digital keys and the decimal
key. Under shift mode, pressing
acts the HELP
function. The LCD display will show more information
about cursor locating place.
9
ENTER
ENTER key: It is to confirm the setting of parameters.
10
RPG: The user can input programming data or options by
turning the RPG to the desired ones.
Main power switch: It is to power on or off.
