Chroma 61603 User Manual

Appendix A Pin Assignment of TTL Signal
A-1
Appendix A Pin Assignment of TTL Signal
9-Pin D-Type Male Connector:
Pin No.
Signal
Pin No.
Signal
1
GND
6
GND
2
/ Remote-Inhibit
7
GND
3
GND
8
/ FAULT-OUT
4
AC-ON
9
---
5
---
/ Remote-Inhibit: When voltage level of this pin becomes LOW, it can inhibit the output
of AC source (See 3.6.1).
AC-ON: When AC source output voltage, this pin will become HIGH, and it becomes LOW
when quit output.
/ FAULT-OUT: The voltage level of this pin is HIGH if AC source is in normal state. It
becomes LOW when AC source is in protection state.
Connecting the / FAULT-OUT signal of TTL PIN8 on AC Source rear panel to TTL PIN8 on
A615003 rear panel as turning on the functions of A615003 thus it can be activated.
