Programmable AC Source 61601/61602/61603/61604 User’s Manual
3-22
The cursor stays in channel 1. The user can press 1 - 9 to select channel or use
, , or press SHIFT then to change page to the destination. The cursor stays in
channel 5 after pressing 5 .
Press ENTER to save the output settings to channel 5. The display will show saving status
for about 3 seconds. The display is shown as below.
Then output settings in MAIN PAGE show in channel 5. The display is shown as below.
Then, press PAGE/EXIT to return to MAIN PAGE.
Recalling from memory channel to MAIN PAGE is shown the following: In MAIN PAGE, press
SHIFT then
/ - to run the RECALL function. The display will show as below:
CHOICE 1 - 9, PRESS (ENTER) TO SAVE MAIN PAGE
1. Vac = 0.0 F = 60.00 Vdc = 0.0
2. Vac = 120.0 F = 60.00 Vdc = 0.0
3. Vac = 0.0 F = 60.00 Vdc = 0.0
CHOICE 1 - 9 , PRESS (ENTER) TO SAVE MAIN PAGE
4. Vac = 0.0 F = 60.00 Vdc = 0.0
5. Vac = 0.0 F = 60.00 Vdc = 0.0
6. Vac = 0.0 F = 60.00 Vdc = 0.0
CHOICE 1 - 9, PRESS (ENTER) TO SAVE MAIN PAGE
4. Vac = 0.0 F = 60.00 Vdc = 0.0
5. Vac = 230.0 F = 50.00 Vdc = 10.0
6. Vac = 0.0 F = 60.00 Vdc = 0.0
CHOICE 1 - 9, PRESS (ENTER) TO RECALL
1. Vac = 0.0 F = 60.00 Vdc = 0.0
2. Vac = 120.0 F = 60.00 Vdc = 0.0
3. Vac = 0.0 F = 60.00 Vdc = 0.0
Saving now, do not shut down ........
