High Power DC Electronic Load 63200 Series Operation & Programming Manual
Set the Master as follows:
Connect the A port of RS485 cable to the selected Master. The start screen is same as the
CC mode settings.
Press SYS to enter into system setting mode. Since the Master setting is not related to RS485
ADDRESS, press ↓→ directly to go to PARALLEL setting screen.
Press 1, ENTER to select MASTER:
It goes to Measurement Display screen:
Select 1 , ENTER: SUM, the total current is set and displayed by MASTER. The current
added to MASTER and SLAVE will divide evenly.
Select 2 , ENTER: It parallels the sole settings of each unit to show the added current.
When the above steps are done, it will go to Slave model selection screen:
Switch the rotary knob on the panel following the slave no. (SLAVE1→6) until the screen
shows the correct model.
Press ↓→ or ↑← to select other number to be paralleled for slave (SLAVE1→6) and repeat
the above setting steps. If the number does not parallel to other slave, press ENTER to skip.
NONE means does not exist. It ends when the setting is done. Select the mode to be tested
can exit the screen to start testing.
CCHA: 0.0000A
CCHB: 0.0000A
PRESS 0 3 TO SELECT
MEASUREMENT DISPLAY
1:SUM 2:SOLE
SLAVE1 MODEL: NONE
PLS ROTATE TO SELECT
SLAVE1 MODEL: 63202
PLS ROTATE TO SELECT
PRESS 0 3 TO SELECT
