Following are the selections of PARALLEL setting functions:
0: NONE: It disables the parallel mode function.
1: MASTER: It sets the Electronic Load as Master (main control unit.)
When setting the Electronic Load as the main control unit in the parallel group,
only the front panel of Master or direct command from PC can control it. It not only
can operate simultaneously but also can inform Slave the current for loading.
2: SLAVE: It sets the Electronic Load to Slave.
3: MASTER SYN: It performs parallel synchronization only. All Master, Slave
loadings need to be inputted separately but the control
movement and usage mode will be determined by the front
panel on MASTER or PC input for synchronization.
The model 63201 to 63210 can be paralleled for use interactively, while the
63211 and 63212 can only be paralleled with the same model.
2.5 Remote Control Connection
The remote operation of Load can be done through GPIB, RS-232 or remote controller.
These connectors on the rear panel connect the Load to the controller or computer. The
GPIB interface of the electronic load is standard. The remote controller is optional. The
63200 series Remote Controller can control the load via RS-232 port. Connect the Remote
Controller to the Electronic Load before powering it on.
PRESS 0 → 3 TO SELECT
PARALLEL = MST SYNC
PRESS 0 → 3 TO SELECT
PARALLEL = MASTER
PRESS 0
→
