Chroma 66200 Series User Manual

Specification
2. Specification (18°C ∼ 28°C, RH ≤ 75%)
Model 66201 66202
Channel
1 1
Parameters
V, Vpk, I, Ipk, W, VA, VAR, PF, CF_I,
F, Is
V, Vpk, I, Ipk, Is, W, VA, VAR, PF,
CF_I, F, Is, THD_V, THD_I, Energy
AC Voltage
Range 150 / 300 / 500Vrms (CF = 1.6) 150 / 300 / 500Vrms (CF = 1.6)
Accuracy
15Hz - 1KHz:
0.1% of reading + 0.08% of range
1KHz - 10KHz:
(0.1% + 0.05%/KHz) of reading + 0.08%
of range
15Hz - 1KHz:
0.1% of reading + 0.08% of range
1KHz - 10KHz:
(0.1% + 0.05%/KHz) of reading + 0.08%
of range
Input Resistance
1MΩ 1MΩ
AC Current
Range 0.01 / 0.1 / 0.4 / 2 Arms (CF=4) 0.2 /2/8/20 Arms (0.2/2/8A range CF = 2,
20A range CF = 4)
0.01/0.1/0.4/2 Arms (CF = 4)
Current
accuracy
(*Note 1)
15Hz - 1KHz:
0.1% of reading + 0.25% range
1KHz - 10KHz:
(0.1% + 0.05%/KHz) of reading + 0.25%
of range
For 0.2/2/8 Arms (CF = 2)
15Hz - 1KHz:
0.1% of reading + 0.12% range
1KHz - 10KHz:
(0.1% + 0.05%/KHz) of reading + 0.12%
of range
For 0.01/0.1/0.4/2 Arms (CF = 4) and
20Arms (CF = 4)
15Hz - 1KHz:
0.1% of reading + 0.25% range
1KHz - 10KHz:
(0.1% + 0.05%/KHz) of reading + 0.25%
of range
Power
Range (W) 1.5W/… /1000W, 12 ranges 1.5W/…/10KW, 24 ranges
Accuracy For Energy Star
0.2% of Reading + 7mW
15Hz - 1KHz:
(0.2%+(0.3/PF)%/KHz) of Reading +
0.33% of Range
1KHz - 10KHz:
(0.2%+0.1%/KHz+(0.3/PF)%/KHz) of
Reading + 0.33% of Range
For Energy Star
0.2% of Reading + 7mW
For 0.2 / 2 / 8 Arms (CF = 2)
15Hz - 1KHz:
(0.2%+(0.3/PF)%/KHz) of Reading +
0.2% of Range
1KHz - 10KHz:
(0.2%+0.1%/KHz+(0.3/PF)%/KHz) of
Reading + 0.2% of Range
For 0.01/0.1/0.4/2 Arms (CF=4) and
20Arms (CF=4)
15Hz - 1KHz:
(0.2%+(0.3/PF)%/KHz) of Reading +
0.33% of Range
1KHz - 10KHz:
(
0.2%+0.1%/KHz+
(
0.3/PF
)
%/KHz
)
of
2-1
