Appendix E Specification Verification
Appendix E Specification Verification
This chapter describes the procedure of specification verification for verifying the functions
of 66200 Series Digital Power Meter. This test procedure is applicable for validating the
instruments of newly purchased and repaired as well as for periodic calibration. The
measurement items provided by 66200 Series Power Meter are based on the 66201 Power
Meter with additional current range test items that are marked by (66202 Only) in the table
below.
Only qualified professional personnel can perform the specification verification. The person
should have professional knowledge of power measurement and is familiar with the test
devices used in this chapter to avoid causing electric shock or other injury during execution.
" WARNING
Do not perform the procedures described in this chapter except qualified personnel to avoid
electric shock.
Hardware Requirements
The test devices required are:
Test Equipment Specification Suggested Model
Voltage Source 0~500Vrms output Fluke 5500A
Current Source 0~20Arms output Fluke 5500A
Test Wire
Withstand voltage 600Vrms
Withstand current 20Arms
Configuring Test Wires
Connect the Fluke 5500A voltage output Hi/Lo to the 66200 Series Power Meter’s rear panel
V+/V- and the Fluke 5500A current output to the 66200 Series Power Meter’s rear panel I+/I-
with test wires as Figure E-1 shows.
Once the instruments are configured, power on the Fluke 5500A and 66201.
E-1
