Appendix F Calibration Procedure
Appendix F Calibration Procedure
This chapter provides the basic adjustment information for 66201 Digital Power Meter. This
procedure can be used to verify the operation of instrument during its periodic specification
verification or after troubleshooting or being repaired to ensure its functionality and
performance.
Only qualified professional personnel can perform the specification verification. The person
should have professional knowledge of power measurement and is familiar with the test
devices used in this chapter to avoid causing electric shock or other injury during execution.
" WARNING
Do not perform the procedures described in this chapter except qualified personnel to avoid
electric shock.
Hardware Requirements
The test devices required are:
Test Equipment Specification Suggested Model
Voltage Source 0~500Vrms output Fluke 5500A
Current Source 0~20Arms output Fluke 5500A
Short Circuit Wire
Withstand voltage 600Vrms
Withstand current 20Arms
Twin banana plugs
Test Wire
Withstand voltage 600Vrms
Withstand current 20Arms
Configuring Test Wires
Connect the Fluke 5500A voltage output Hi/Lo to the 66200 Series Power Meter’s rear panel
V+/V- and the Fluke 5500A current output to the 66200 Series Power Meter’s rear panel I+/I-
with test wires as Figure F-1 shows.
Once the instruments are configured, power on the Fluke 5500A and 66200 Series Power
Meter.
a CAUTION
Be sure the voltage and current wire position are connected correctly. It could burn out the
instrument internal circuit if mistake.
F-1
