Technical Specifications
Control panel
12V DC 500mA
850 / 900 / 1800 / 1900MHz
≤ 110mA
≤ 340mA
Lithium-Ion battery 3,7V 800mA
BL-5B (2x)
95dB
10 x Remote control
50 x Sensor
50 x RFID Tag
315MHz or 433.92MHz (±75MHz)
-10 to +55 degrees celcius
≤ 80% (non-condensing)
188 x 132 x 26 mm
Power Supply
GSM Frequency
Standby Current
Alarm Current
Back-up Batter y
Built-in Siren
Maximum Wireless Accessories
Radio Frequency
Temperature
Relative Humidity
Dimensions (LxWxH)
Installing Control Panel
The control panel can be mounted to the wall or can be put on a bracket on a desk
with the included accessories showed below.
Wall mount
When mounting the control panel to the wall, first apply the walll mount to the wall
with included screws. Now you can slide the control panel into the wall mount top to
bottom on the plugs. The wall mount secures the tamper switch is pressed.
Desk stand
With the desk stand it is possible to place the control panel on a flat surface. The desk
stand can be mounted on the control panel by sliding it from top to bottom.
IMPORTANT: Avoid pressing the tamper switch several times in a row, this may
cause the system to reset.
Desk stand Wall mount
≤ 80m(open area/no interface)
Transmitting Distance
ABS plastic+Acrylic
Housing Material
PIR-900 Wireless PIR Motion Detector
1.
2.
3.
1.
2.
3.
IMPORTANT: When single zone group is selected, the sensor will always be in
the normal group. It is not possible to place it in the home group.
3 Years
Warranty
