2-6 Installation
5150 Service Aggregation Switch Hardware Installation and Start-up Manual
009-3222-001 Standard Revision H
Copyright
©
2012-2015 Ciena
®
Corporation July 2015
If your installation site allows rear access to the chassis, you can install the
supplemental ground connection after the chassis is mounted. However, if you
will not be able to access the rear of the unit after it is mounted, you will need
to install the supplemental ground connection before mounting the chassis in
the cabinet or frame.
See “To Install Supplemental Ground” on page 2-18 for a procedure.
10 Gigabit Ethernet Module(s)
The 10 Gigabit Ethernet module is an optional module. Table 2-1 provides a
summary of the available modules.
All of the 10 Gigabit Modules provide two 10 Gigabit Ethernet ports with XFP
connectors. These option modules both support standard and synchronous
Ethernet. The 10 Gigabit Ethernet Pluggable Option modules are not hot
swappable. The system must be powered down to install or replace these
modules.
When only one module is being installed, it can be installed in either slot.
Functionality is determined by the module type, and not the slot it is installed
in.
Table 2-1
10 Gigabit Ethernet Pluggable Module Summary
Module Description Number per
5150
Notes
Standard
(170-5101-900)
2 x 10 GbE Dual XFP
Module
1 or 2 —
Extended Features
(170-5100-900)
2 x 10 GbE Dual XFP
Module with extended
features
1 or 2 Hardware capable for a number of
advanced features such as:
• PBB-TE tunneling and optimization
protocols
• hardware acceleration for AT&T
TWAMP, 802.1ag CFM CCMs and
Y.1731 management and performance
measurement messages
Standard with BITS
(170-5102-900)
2 x 10 GbE Dual XFP
Module with single BITS
interface
1 The BITS interface can be configured to
provide either BITS-IN or BITS-OUT.
Only one of these modules can be
installed in the 5150. Either slot can be
used.
This module requires SAOS release
6.10.1 as the minimum software
release.
