4-4 Maintenance
5150 Service Aggregation Switch Hardware Installation and Start-up Manual
009-3222-001 Standard Revision H
Copyright
©
2012-2015 Ciena
®
Corporation July 2015
Procedure 4-1
To Add a 10 Gigabit Ethernet Module
Step Action
1 Remove power from the 5150 by disabling input power to both PS A and
PS B.
The PWR LED on the front of the 5150 is now off and the unit is unpowered.
2 Using a Phillips screwdriver, remove the two screws holding the filler plate in
place.
3 Set aside the filler plate and screws.
4 Remove the 10 Gigabit Ethernet module from the packaging and inspect for
damage.
5 Gently slide the module into the exposed slot.
6 Secure the module in place using the two captive screws on the left and right
side of the module.
When the 5150 is powered on, the 10 Gigabit Ethernet option module will
initialize after it is installed. Initialization will be shown by a blinking green
Status LED. For more information see “10 Gigabit Ethernet Pluggable Module
LEDs” on page 5-4.
7 Restore power to the input DC circuits for PS A and PS B.
The power supplies will turn on.
8 Verify the LEDs. The following LED indications should be present on the
5150:
• PS A — Status LED is solid green, Input LED is solid green
• PS B — Status LED is solid green, Input LED is solid green
• PWR — solid green
• 10 Gigabit Module Status — Status LED is blinking green during
initialization) and turns to solid green once the module is booted and
working.
The 10 Gigabit Ethernet module has been installed. You are now ready
to add XFPs to the ports. For assistance see “To Install a Pluggable
Optic” on page 2-27.
CAUTION: Operating the 5150 without either the module(s) or the filler plate(s)
installed will result in airflow issues and is not recommended. Ensure that the
10 Gigabit Ethernet Option Modules or the filler plates for these slots are installed
before using the system.
