LE-3xx/LE-4xx Hardware Installation & User Guide
POWER CORD AND POWER CORD RESTRAINTS
CUIDADO:
Todos os cabos de alimentao devem atender s exigncias dos cdigos
eltricos locais e nacionais antes da instalao.
注意：インストール前すべての AC 電源コードが地域および国の電気関連法
規の要件を満たしていることを確認してください。
To avoid the inadvertent disconnection of the power supply cord, Ciena/World Wide Packets
offers power cord retainer clips (purchased separately). These clips restrain the cord, thus
relieving the cord weight from the connector. For devices with a fixed power supply, a cord
saddle retainer is snapped into the fan outlet grid. For devices with removable power supplies,
a twistable cord retainer is used. Contact Ciena/World Wide Packets Sales to purchase these
retainer clips.
Power Cord Saddle Retainer Installation (fixed power supplies):
Figure 2-4:
Cord Saddle Retainer Installation
1.
With the retainer oriented vertically (see
Figure 2-4
), insert it into the fan grid
opening that is closest to the power receptacle and centered vertically on the fan
grid. This ensures the least amount of air flow restriction.
2.
Plug the power cord firmly into the device's power receptacle.
3.
Route the power cord through the retainer clip.
4.
The power cord can now be plugged into a power source.
