3.4.11 USER PASSCODE
Select the USER PASSCODE menu (Image 3.4.35) to access the USER PASSCODE sengs.
USER PASSCODE sengs (Image 3.4.36) include: PASSCODE and ENABLE.
Table 3.4.10 · IO seng descripons, opons and default values (connued)
Image 3.4.35 · USER PASSWORD menu
Select USER
PASSCODE menu
Image 3.4.36 · PASSCODE sengs
SETTING DESCRIPTION
OPTIONS
DEFAULT
PERMSVE
(PERMISSIVE)
MODE
Seng Logical State Electrical State Mode
N.C.
Normally Open
(N.O.)
Inacve
Open N.C.
N.O.
Acve
Closed
Normally Closed
(N.C.)
Acve
Open
Inacve
Closed
PS1 MODE Same as PERMISSIVE MODE Same as PERMISSIVE MODE N.O.
PS2 MODE Same as PERMISSIVE MODE Same as PERMISSIVE MODE N.O.
PoC (Proof of
Closure) MODE
Same as PERMISSIVE MODE Same as PERMISSIVE MODE N.C.
