Cimarron ARCONTROL BMS - Page 59

57
Table 3.5.1 · MODBUS register map - conguraon registers (connued)
REGISTER
NUMBER
NAME DESCRIPTION
OPTIONS and
REGISTER VALUE
DEFAULT
DATA
TYPE
READ
or
WRITE
12
PILOT EST
TIME
Length of me required that
pilot ame is to be connuously
detected before transioning to
the PILOT ON state.
Range Value
3 UINT16 R/WMin 0
Max 5
13
PILOT ON
DEMAND
Enables or disables the pilot
on demand funconality (only
available in AUTOMATIC mode).
Mode Value
0 UINT16 R/WENABLED 1
DISABLED 0
14
BMS HIGH
TEMP LIMIT
Temperature limit of the BMS dual
channel thermocouple that triggers
a high temperature lockout
Range °F °C
1600 INT16 R/WMIN 100 38
MAX 2460 1348
15 - 19 UNUSED Unused N/A R
20
PROCESS 1
SOURCE
Input to be used as Process 1
process variable
Source Value
4 UINT16 R/W
Ø (NONE) 0
TC1 1
TC2 2
TC BMS 3
XDCR 4
21
PROCESS 1
LOGIC
Operang logic of Process 1
Logic Value
0 UINT16 R/W
HIGH ON
LOW OFF
0
HIGH OFF
LOW ON
1
WINDOW 2
INV
WINDOW
3
22
PROCESS 1
HIGH LEVEL
Process 1 upper limit
Range Value
50 INT16 R/WMin -32768
Max 32768
23
PROCESS 1
LOW LEVEL
Process 1 lower limit
Range Value
20 INT16 R/WMin -32768
Max 32768
24
PROCESS 1
CEILING
Upper limit to user adjustable
Process 1 high level from the Status
Menu (Must be lower than Process
1 High Level)
Range Value
100 INT16 R/WMin -32768
Max 32768
25
PROCESS 1
FLOOR
Lower limit to user adjustable
Process 1 low level from the
Status Menu (Must be higher than
Process 1 Low Level)
Range Value
10 INT16 R/WMin -32768
Max 32768
