Cimarron ARCONTROL BMS - Page 60

58
Table 3.5.1 · MODBUS register map - conguraon registers (connued)
REGISTER
NUMBER
NAME DESCRIPTION
OPTIONS and
REGISTER VALUE
DEFAULT
DATA
TYPE
READ
or
WRITE
26 - 29 UNUSED Unused N/A R
30
PROCESS 2
SOURCE
Input to be used as Process 2
process variable
Source Value
0 UINT16 R/W
Ø (NONE) 0
TC1 1
TC2 2
TC BMS 3
XDCR 4
31
PROCESS 2
LOGIC
Operang logic of Process 2
Logic Value
0 UINT16 R/W
HIGH ON
LOW OFF
0
HIGH OFF
LOW ON
1
WINDOW 2
INV
WINDOW
3
32
PROCESS 2
HIGH LEVEL
Process 2 upper limit
Range Value
150 INT16 R/WMin -32768
Max 32768
33
PROCESS 2
LOW LEVEL
Process 2 lower limit
Range Value
120 INT16 R/WMin -32768
Max 32768
34
PROCESS 2
CEILING
Upper limit to user adjustable
Process 2 high level from the Status
Menu (Must be lower than Process
2 High Level)
Range Value
32767 INT16 R/WMin -32768
Max 32768
35
PROCESS 2
FLOOR
Lower limit to user adjustable
Process 2 low level from the
Status Menu (Must be higher than
Process 2 Low Level)
Range Value
-32768 INT16 R/WMin -32768
Max 32768
36 - 39 UNUSED Unused N/A R
40
PROCESS 3
SOURCE
Input to be used as Process 3
process variable
Source Value
0 UINT16 R/W
Ø (NONE) 0
TC1 1
TC2 2
TC BMS 3
XDCR 4
