Cimarron ARCONTROL BMS - Data Logs

59
Table 3.5.1 · MODBUS register map - conguraon registers (connued)
REGISTER
NUMBER
NAME DESCRIPTION
OPTIONS and
REGISTER VALUE
DEFAULT
DATA
TYPE
READ
or
WRITE
41
PROCESS 3
LOGIC
Operang logic of Process 3
Logic Value
0 UINT16 R/W
HIGH ON
LOW OFF
0
HIGH OFF
LOW ON
1
WINDOW 2
INV
WINDOW
3
42
PROCESS 3
HIGH LEVEL
Process 3 upper limit
Range Value
150 INT16 R/WMin -32768
Max 32768
43
PROCESS 3
LOW LEVEL
Process 3 lower limit
Range Value
150 INT16 R/WMin -32768
Max 32768
44
PROCESS 3
CEILING
Upper limit to user adjustable
Process 3 high level from the Status
Menu (Must be lower than Process
3 High Level)
Range Value
32767 INT16 R/WMin -32768
Max 32768
45
PROCESS 3
FLOOR
Lower limit to user adjustable
Process 3 low level from the
Status Menu (Must be higher than
Process 3 Low Level)
Range Value
-32768 INT16 R/WMin -32768
Max 32768
46 - 49 UNUSED Unused N/A R
50
PROCESS IND
SOURCE
Input to be used as the
Independent Process process
variable
Source Value
0 UINT16 R/W
Ø (NONE) 0
TC1 1
TC2 2
TC BMS 3
XDCR 4
51
PROCESS IND
LOGIC
Operang logic of Independent
Process
Logic Value
0 UINT16 R/W
HIGH ON
LOW OFF
0
HIGH OFF
LOW ON
1
WINDOW 2
INV
WINDOW
3
