Table 3.5.2 · MODBUS register map - variable registers
REGISTER
NUMBER
NAME
DESCRIPTION
DATA
TYPE
READ
or
WRITE
201 PROCESS 1 VALUE
Range Value
INT16 RMin -32768
Max 32767
202
PROCESS 2 VALUE
Range Value
INT16 RMin -32768
Max 32767
203
PROCESS 3 VALUE
Range Value
INT16 RMin -32768
Max 32767
204
PROCESS IND VALUE
Range Value
INT16 R
Min -32768
Max 32767
205
SHUTDOWN 1 VALUE
Range Value
INT16 RMin -32768
Max 32767
206
SHUTDOWN 2 VALUE
Range Value
INT16 RMin -32768
Max 32767
207
SHUTDOWN 3 VALUE
Range Value
INT16 RMin -32768
Max 32767
208
PID PROCESS VALUE
Range Value
INT16 RMin -32768
Max 32767
209 PID CONTROL VALUE
Range Value
INT16 RMin -100
Max 100
210 TC 1 VALUE
Range Value
INT16 RMin -32768
Max 32768
211 TC 2 VALUE
Range Value
INT16 RMin -32768
Max 32767
