Cimarron ARCONTROL BMS - USB Drive Port Functions

68
3.5.2 VARIABLE REGISTERS
Table 3.5.2 · MODBUS register map - variable registers
REGISTER
NUMBER
NAME DESCRIPTION
DATA
TYPE
READ
or
WRITE
200 CURRENT SYSTEM STATE
Mode
Value in
AUTOMATIC
mode
Value in
MANUAL
mode
UINT16 R
STOPPED 1 1
START-UP 2 2
DIAGNOSTIC 3 3
PRE-PURGE 5 5
IGNITE 6 6
PURGE 7 N/A
WAIT 8 N/A
EST PILOT 9 N/A
PILOT ON 15 15
IDLE 16 16
ACTIVE PRCS 1 20 20
ACTIVE PRCS 2 21 21
ACTIVE PRCS 3 22 22
ACTIVE PRCS 1,2 25 25
ACTIVE PRCS 1,3 26 26
ACTIVE PRCS 2,3 27 27
ACTIVE PRCS ALL 30 30
PILOT FAIL 35 35
POC FAIL 36 36
LOW BATTERY 37 37
PERMISSIVEOPEN 38 38
SHUTDOWN 1 40 40
SHUTDOWN 2 41 41
SHUTDOWN 3 42 42
BMS FAULT 45 45
