74
Table 3.6.3 · Shutdown 1, 2, or 3 data
Table 3.6.4 · Digital data
Table 3.6.5 · Analog data
GROUP HEADER DESCRIPTION
DIGITAL DATA
FLAME INDICATOR State of PILOT STATUS output
ALARM State of Alarm output
ALARM MODE Mode of Alarm output (N.O., N.C.)
SWITCH 1 PS1 input state (Acve, Inacve)
SWITCH 1 MODE Mode of PS1 input (N.O., N.C.)
SWITCH 2 PS2 input state
SWITCH 2 MODE Mode of PS2 input
POC PROOF OF CLOSURE input state
POC MODE Mode of PROOF OF CLOSURE Input
PERMISSIVE PERMISSIVE input state
PERMISSIVE MODE Mode of PERMISSIVE input
FLAMESENSE GRADE Grade of ame sense (A, B, C, D, F)
GROUP HEADER DESCRIPTION
ANALOG DATA
TEMPERATURE UNITS System temperature units (FAHRENHEIT, CELSIUS)
AMBIENT TEMPERATURE Ambient temperature inside of the enclosure
THERMOCOUPLE 1 Thermocouple 1 temperature
THERMOCOUPLE 2 Thermocouple 2 temperature
THERMOCOUPLE BMS Temperature of the BMS Module thermocouple
TRANSDUCER Transducer value. Does not show decimal point
TRANSDUCER UNITS
Tranducer units (psi, oz/in
2
, etc…)
PID SETPOINT Setpoint of the PID controller
PID CONTROL VARIABLE Control variable of the PID controller (current value of input)
BATTERY VOLTAGE Baery voltage in volts
SOLAR VOLTAGE Solar voltage in volts
GROUP HEADER DESCRIPTION
SHUTDOWN 1, 2,
or 3
(Note: Each
shutdown has
unique data)
LOGIC Shutdown logic seng
SOURCE Shutdown source seng
CURRENT VALUE Value of shutdown source
HIGH LEVEL Shutdown high level seng
LOW LEVEL Shutdown low level seng
