----- Supply network analyzer CVMk and CVMk-ITF ------ Page Nº 39
) Output of the power factor parameter ( P.F.):
0/4 mA ---------------------------- -------------------------20 mA
+0.00 Ind. 1.00 Cap. – 0.00
3.- Default full scale:
Parameter Condition Full scale ( 20 mA )
Voltages Primary < 500 Primary x 500 /secondary
(V) Primary > 500 Voltage primary
Currents (A) Current primary
Powers For one phase voltage primary x current primary / 1000
(kW) Three phase value voltage primary x current primary x 3 / 1000
Frequency (Hz) 65
P.F. – 0.00
4.- Connections to directly have a voltage output: 0 - 2 V c.c.
Connections of the module DB-9 connector:
Terminals Signal Terminals
Signal
Channel
6 - 7 make a bridge
Channel
8 - 9 make a bridge
1
1(+)
2
5(+)
2 (-) common 4 (-) common
