Cisco Aironet 1552 Series for Hazardous Locations Installation Guide
Chapter 3 Installing the 1552 Series Access Points in Hazardous Locations
Installation Details for the 1552SA and 1552SD Access Point
Figure 3-17 Routing Detail
Step 7 Complete the connections inside the 1552 as shown in Figure 3-18.
Figure 3-18 Inside Connectivity
1 ERT50 Junction Box 2 ERT50 Junction Box Cover (removed)
3 1/2NPT 4 Power Cable
5 Fiber Cable 6 1/2NPT
7 1/2NPT 8 1/2NPT Male to Male
