44-13
Cisco Catalyst Blade Switch 3130 and 3032 for Dell Software Configuration Guide
OL-12247-04
Chapter 44 Configuring IP Multicast Routing
Configuring IP Multicast Routing
To disable multicasting, use the no ip multicast-routing distributed global configuration command. To
return to the default PIM version, use the no ip pim version interface configuration command. To
disable PIM on an interface, use the no ip pim interface configuration command.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
ip multicast-routing distributed Enable IP multicast distributed switching.
Step 3
interface interface-id Specify the Layer 3 interface on which you want to enable multicast
routing, and enter interface configuration mode.
The specified interface must be one of the following:
• A routed port: a physical port that has been configured as a Layer 3
port by entering the no switchport interface configuration
command.
• An SVI: a VLAN interface created by using the interface vlan
vlan-id global configuration command.
These interfaces must have IP addresses assigned to them. For more
information, see the “Configuring Layer 3 Interfaces” section on
page 11-24.
Step 4
ip pim version [1 | 2] Configure the PIM version on the interface.
By default, Version 2 is enabled and is the recommended setting.
An interface in PIMv2 mode automatically downgrades to PIMv1 mode
if that interface has a PIMv1 neighbor. The interface returns to Version
2 mode after all Version 1 neighbors are shut down or upgraded.
For more information, see the “PIMv1 and PIMv2 Interoperability”
section on page 44-11.
Step 5
ip pim {dense-mode | sparse-mode |
sparse-dense-mode}
Enable a PIM mode on the interface.
By default, no mode is configured.
The keywords have these meanings:
• dense-mode—Enables dense mode of operation.
• sparse-mode—Enables sparse mode of operation. If you configure
sparse mode, you must also configure an RP. For more information,
see the “Configuring a Rendezvous Point” section on page 44-24.
• sparse-dense-mode—Causes the interface to be treated in the mode
in which the group belongs. Sparse-dense mode is the recommended
setting.
Step 6
end Return to privileged EXEC mode.
Step 7
show running-config Verify your entries.
Step 8
copy running-config startup-config (Optional) Save your entries in the configuration file.
