Chapter 36 Configuring QoS
Configuring Standard QoS
Configuring the IP-Precedence-to-DSCP Map
You use the IP-precedence-to-DSCP map to map IP precedence values in incoming packets to a DSCP
value that QoS uses internally to represent the priority of the traffic.
Table 36-13 shows the default IP-precedence-to-DSCP map:
If these values are not appropriate for your network, you need to modify them.
Beginning in privileged EXEC mode, follow these steps to modify the IP-precedence-to-DSCP map.
This procedure is optional.
To return to the default map, use the no mls qos ip-prec-dscp global configuration command.
This example shows how to modify and display the IP-precedence-to-DSCP map:
Switch(config)# mls qos map ip-prec-dscp 10 15 20 25 30 35 40 45
Switch(config)# end
Switch# show mls qos maps ip-prec-dscp
IpPrecedence-dscp map:
ipprec: 0 1 2 3 4 5 6 7
--------------------------------
dscp: 10 15 20 25 30 35 40 45
Table 36-13 Default IP-Precedence-to-DSCP Map
IP Precedence Value DSCP Value
00
18
216
324
432
540
648
756
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
mls qos map ip-prec-dscp
dscp1...dscp8
Modify the IP-precedence-to-DSCP map.
For dscp1...dscp8, enter eight DSCP values that correspond to the IP
precedence values 0 to 7. Separate each DSCP value with a space.
The DSCP range is 0 to 63.
Step 3
end Return to privileged EXEC mode.
Step 4
show mls qos maps ip-prec-dscp Verify your entries.
Step 5
copy running-config startup-config (Optional) Save your entries in the configuration file.
