Chapter 29 Configuring LLDP, LLDP-MED, and Wired Location Service
Configuring LLDP, LLDP-MED, and Wired Location Service
• Device category is specified as a wired station
• State is specified as delete
• Serial number, UDI
• Time in seconds since the switch detected the disassociation
When the switch shuts down, it sends an attachment notification with the state delete and the IP address
before closing the NMSP connection to the MSE. The MSE interprets this notification as disassociation
for all the wired clients associated with the switch.
If you change a location address on the switch, the switch sends an NMSP location notification message
that identifies the affected ports and the changed address information.
Configuring LLDP, LLDP-MED, and Wired Location Service
• Default LLDP Configuration, page 29-4
• Configuration Guidelines, page 29-4
• Enabling LLDP, page 29-5
• Configuring LLDP Characteristics, page 29-5
• Configuring LLDP-MED TLVs, page 29-6
• Configuring Network-Policy TLV, page 29-7
• Configuring Location TLV and Wired Location Service, page 29-9
Default LLDP Configuration
Configuration Guidelines
• If the interface is configured as a tunnel port, LLDP is automatically disabled.
Table 29-1 Default LLDP Configuration
Feature Default Setting
LLDP global state Disabled
LLDP holdtime (before discarding) 120 seconds
LLDP timer (packet update frequency) 30 seconds
LLDP reinitialization delay 2 seconds
LLDP tlv-select Disabled to send and receive all TLVs
LLDP interface state Disabled
LLDP receive Disabled
LLDP transmit Disabled
LLDP med-tlv-select Disabled to send all LLDP-MED TLVs
