10-16
Cisco Wireless LAN Controller Configuration Guide
OL-17037-01
Chapter 10 Managing User Accounts
Choosing the Web Authentication Login Page
These are the available status codes:
• Status Code 1: “You are already logged in. No further action is required on your part.”
• Status Code 2: “You are not configured to authenticate against web portal. No further action is
required on your part.”
• Status Code 3: “The username specified cannot be used at this time. Perhaps the username is already
logged into the system?”
• Status Code 4: “You have been excluded.”
• Status Code 5: “The User Name and Password combination you have entered is invalid. Please try
again.”
Note For additional information, refer to the External Web Authentication with Wireless LAN Controllers
Configuration Example at this URL:
http://www.cisco.com/en/US/tech/tk722/tk809/technologies_configuration_example09186a008067489
f.shtml
Using a Customized Web Authentication Login Page from an External Web
Server
If you want to use a customized web authentication login page that you configured on an external web
server, follow the instructions in the GUI or CLI procedure below. When you enable this feature, the user
is directed to your customized login page on the external web server.
Note You must configure a preauthentication access control list (ACL) on the WLAN for the external web
server and then choose this ACL as the WLAN preauthentication ACL under Security Policies > Web
Policy on the WLANs > Edit page. See Chapter 5 for more information on ACLs.
Using the GUI to Choose a Customized Web Authentication Login Page from an External Web Server
Step 1 Click Security > Web Auth > Web Login Page to open the Web Login page (see Figure 10-12).
Figure 10-12 Web Login Page
