11-26
Cisco Wireless LAN Controller Configuration Guide
OL-17037-01
Chapter 11 Configuring Radio Resource ManagementWireless Device Access
Overriding RRM
Statically Assigning Channel and Transmit Power Settings to Access Point
Radios
This section provides instructions for statically assigning channel and power settings using the GUI or
CLI.
Note Cisco recommends that you assign different nonoverlapping channels to access points that are within
close proximity to each other. The nonoverlapping channels in the U.S. are 36, 40, 44, 48, 52, 56, 60,
64, 149, 153, 157, and 161 in an 802.11a network and 1, 6, and 11 in an 802.11b/g network.
Note Cisco recommends that you do not assign all access points that are within close proximity to each other
to the maximum power level.
Using the GUI to Statically Assign Channel and Transmit Power Settings
Follow these steps to statically assign channel and/or power settings on a per access point radio basis
using the GUI.
Step 1 Click Wireless > Access Points > Radios > 802.11a/n or 802.11b/g/n to open the 802.11a/n (or
802.11b/g/n) Radios page (see Figure 11-7).
Figure 11-7 802.11a/n Radios Page
This page shows all the 802.11a/n or 802.11b/g/n access point radios that are joined to the controller and
their current settings. The Channel field shows both the primary and extension channels and uses an
asterisk to indicate if they are globally assigned.
Step 2 Hover your cursor over the blue drop-down arrow for the access point for which you want to modify the
radio configuration and choose Configure. The 802.11a/n (or 802.11b/g/n) Cisco APs > Configure page
appears (see Figure 11-8).
