Cisco 700 series Configuration Guide

Using CHAP 4-3
Remote Cisco 765 Command Summary
Remote Cisco 765 Command Summary
Following is the command summary for configuring the remote Cisco 765 series router for
IP static routing and callback with CHAP authentication:
set switch 5ess
set
1 dir directory_number
set 2 dir directory_number
set system 765
set ppp authentication incoming chap
set ppp secret client
set multidestination on
cd lan
set ip address
192.168.147.9
set ip netmask 255.255.255.248
set ip routing on
set ip rip update periodic
set ip rip receive v2
set ip rip version 2
set user
4500
set ppp secret client
set ppp secret host
set ip route destination
0.0.0.0 gateway 172.16.125.1 propagate on
set ip address
172.16.125.7
set ip netmask 255.255.255.0
set ip routing on
set ip framing none
set ppp callback request always
set
1 ringback number
set 2 ringback number
set number 5558011
set bridging off
set ip rip update off
set timeout
360
set active
reboot
Multilink PPP is enabled by default. If the Cisco 700 series router is dialing into a host that
does not support multilink PPP or that does not have multilink PPP enabled, the Cisco 700
series router might report a misconfiguration. This is most commonly seen when the
Cisco 700 series router is connected to equipment from Ascend.

Cisco 700 series Specifications

General

Wireless	No
Compression	No
WAN Ports	1
Weight	0.48 kg
Power Supply	External
Category	Network Router
