Cisco 700 series Configuration Guide

IP Unnumbered Static Routing and CHAP with MLP
Cisco700 Series Router Configuration Guide
4-8
IP Unnumbered Static Routing and CHAP with MLP
This section describes how to configure the central site Cisco 4500 series router and the
remote Cisco 765 series router for Internet Protocol (IP) unnumbered routing with
Challenge Handshake Authentication Protocol (CHAP) authentication and Multilink
Protocol (MLP).
Figure 4-4 is an illustration of the configuration used in this example.
Figure 4-4 IP Unnumbered Routing and CHAP Authentication with MLP
ISDN network
Ethernet interface
IP address: 172.18.124.2
IP subnet mask: 255.255.255.0
Remote router
ISDN number: 5553693/4
User profile name: 4500
Central site router
ISDN number: 5558011/2
Host name: 4500
Ethernet interface
IP address: 192.168.147.9
IP subnet mask: 255.255.255.248
Telecommuter PC
IP address:
192.168.147.8
Central site network
IP network: 172.18.124.0
Serial interface
IP unnumbered
Serial interface
IP unnumbered
S4769
765
4500
